IFYOO G53 Wireless Vertical Ergonomic Mouse

1. Isingeniso

The IFYOO G53 Wireless Vertical Ergonomic Mouse is designed to provide superior comfort and enhance productivity. Its unique vertical design promotes a natural handshake position, reducing wrist strain and discomfort often associated with traditional mice. This tri-mode mouse offers versatile connectivity options and customizable features to adapt to various computing environments.

Figure 1.1: IFYOO G53 Wireless Vertical Ergonomic Mouse.

2. Izici Eziyinhloko

• Superior Ergonomic Design: Keeps your hand in a natural handshake position to reduce wrist stress and pain, helping to prevent Carpal Tunnel Syndrome.
• Ukuxhumana Kwemodi Ezintathu: Supports 2.4GHz wireless, Bluetooth 5.1, and wired USB-C connections, allowing seamless switching between multiple devices.
• I-DPI elungisekayo: Max 8400 DPI for smooth and accurate tracking, with multiple DPI settings (500, 1600, 2400, 3200, 4000, 4800, 8400) for precise control.
• I-Dynamic RGB Lighting: Features 9 RGB lighting modes for customizable visual effects, which can also be turned off. DPI changes are indicated by logo color.
• 5 Programmable Side Buttons: Boost productivity with shortcuts for forward/backward webpage navigation, changing lighting effects, opening file explorer, or returning to desktop. (Note: Some side button shortcuts may not work with Mac OS, iPad OS, and other operating systems, except for light switch, and are primarily supported on Windows 10/11).
• Ibhethri Elishajwa kabusha: Built-in 600mAh rechargeable battery with intelligent power saving. Charges via USB-C.

Figure 2.1: Ergonomic design promotes a natural hand position, reducing wrist strain.

3. Okuqukethwe Kwephakheji

Sicela uqinisekise ukuthi zonke izinto zikhona kuphakheji:

• 1x IFYOO G53 Wireless Vertical Ergonomic Mouse
• 1x Incwadi Yomsebenzisi (le dokhumenti)
• 1x Ikhebuli yokushaja ye-USB yohlobo C
• 1x 2.4 GHz USB Receiver (stored at the bottom of the mouse)

4. Setha

4.1 Ukushaja Igundane

Before first use, it is recommended to fully charge the mouse. Connect the provided USB-C cable to the charging port on the front of the mouse and the other end to a USB power source (e.g., computer USB port, USB wall adapter). The RGB lighting may indicate charging status.

4.2 Ukuxhuma Kudivayisi Yakho

The G53 mouse offers three connection modes:

1. 2.4GHz Imodi engenantambo:
   • Locate the 2.4 GHz USB receiver stored in the magnetic compartment at the bottom of the mouse.
   • Xhuma isamukeli se-USB embotsheni ye-USB etholakalayo kukhompuyutha yakho.
   • Slide the mode switch at the bottom of the mouse to the "2.4G" position. The mouse should connect automatically.
2. Imodi ye-Bluetooth (BT):
   • Slide the mode switch at the bottom of the mouse to the "BT" position.
   • On your device (Windows, Mac, iPad OS, Android), go to Bluetooth settings and search for new devices.
   • Select "IFYOO G53" from the list of available devices to pair.
3. Imodi enentambo:
   • Connect the provided USB-C cable to the mouse's charging port and the USB-A end to your computer's USB port.
   • Slide the mode switch at the bottom of the mouse to the "Wired" position. The mouse will function as a wired device and charge simultaneously.

Figure 4.1: Seamless multi-device connectivity with 2.4G, Wired, and Bluetooth modes.

4.3 Driver Software (Windows Only)

To modify mouse configurations and customize buttons (excluding light switch), driver software is available for Windows OS only. Visit www.ifyoo.net to download the latest driver. This software allows for personalized profiles, macro settings, and advanced RGB control.

Figure 4.2: Professional driver software interface for Windows customization.

5. Iziqondiso Zokusebenza

5.1 Imisebenzi Yenkinobho

The IFYOO G53 mouse features 10 buttons for enhanced control:

Figure 5.1: Mouse layout and button overview.

• Left Button (1): Umsebenzi ojwayelekile wokuchofoza kwesokunxele.
• Isondo Lokuskrola (2): Skrolela phezulu/phansi, chofoza maphakathi.
• Right Button (3): Umsebenzi wokuchofoza kwesokudla okuvamile.
• Inkinobho ye-DPI (4): Ijikeleza ngezilungiselelo ze-DPI.
• Forward Button (5): Izulazula iye phambili web iziphequluli/izinhlelo zokusebenza.
• Backward Button (6): Izulazula ihlehle ingene web iziphequluli/izinhlelo zokusebenza.
• Light Effect Button (7): Changes RGB lighting modes.
• File Resource Manager (8): Ivula File Explorer (Windows only).
• BOSS Button (9): Returns to desktop (Windows only).
• Mode Indicator (10): Displays current connection mode.
• 2.4G Receiver (11): USB dongle for 2.4GHz wireless connection.
• Inkinobho yemodi (12): Switch between 2.4G, Wired, and BT modes.

Note: Due to system compatibility, functions of buttons 5, 6, 8, and 9 can only be used on Windows OS.

5.2 Adjusting DPI Sensitivity

Cindezela inkinobho DPI Button (4) to cycle through the available DPI settings. Each change in DPI will typically be indicated by a change in the logo's LED color, allowing you to visually confirm your current sensitivity level.

Figure 5.2: Adjustable DPI up to 8400, with logo color indicating current DPI.

5.3 Controlling RGB Lighting

Cindezela inkinobho Light Effect Button (7) to cycle through the 9 dynamic RGB lighting modes. Continue pressing to find your preferred effect or to turn the lighting off.

6. Isondlo

• Ukuhlanza: Sebenzisa indwangu ethambile, eyomile ukuhlanza igundane. Ngokungcola okunenkani, kancane dampzu indwangu ngamanzi noma isixazululo esithambile sokuhlanza. Gwema amakhemikhali anokhahlo noma izinto ezilumayo.
• Isitoreji: When not in use for extended periods, store the mouse in a cool, dry place. Ensure the 2.4 GHz receiver is stored securely in its compartment at the bottom of the mouse.
• Ukunakekelwa kwebhethri: To prolong battery life, avoid fully discharging the mouse frequently. Charge it when the battery indicator is low.

7. Ukuxazulula izinkinga

• Igundane aliphenduli:
  • Qinisekisa ukuthi igundane lishajiwe.
  • Check the connection mode switch (2.4G, Wired, BT) is in the correct position.
  • For 2.4GHz, ensure the USB receiver is securely plugged in. Try a different USB port.
  • Nge-Bluetooth, qinisekisa ukuthi i-Bluetooth ivuliwe kudivayisi yakho futhi igundane limatanisiwe. Zama ukuphinda ubhanqe.
  • In wired mode, ensure the USB-C cable is properly connected.
• Cursor movement is erratic or slow:
  • Lungisa isethingi ye-DPI usebenzisa inkinobho ye-DPI.
  • Ensure the mouse sensor is clean and free from debris.
  • Sebenzisa igundane endaweni ehlanzekile, engabonisi ukukhanya noma endaweni yokugcina igundane.
• Side buttons not working (Mac OS/iPad OS):
  • As noted, some side button functions (Forward, Backward, File Resource Manager, BOSS Button) are system-specific and primarily supported on Windows OS. The Light Effect Button should function across all compatible OS.

8. Imininingwane

9. Iwaranti & Ukusekela

9.1 Iwaranti Yonyaka owodwa

IFYOO offers a 90-day free replacement and one-year warranty service from the date of purchase. If there are any problems with the product, please do not hesitate to contact us.

9.2 Ukwesekwa Kwamakhasimende

• Esemthethweni Webindawo: www.ifyoo.net
• I-imeyili Yesevisi Yekhasimende: cs@ifyoo.net (9:00 - 18:00 Monday to Friday)
• Manuals, Drivers, Firmware Updates: support.ifyoo.net
• Okokufundisa kwevidiyo: www.youtube.com/IFYOO
