1. Umkhiqizo Uphelileview
I-Simarine ST107 iyizinga lethangi ledijithali eliguquguqukayo kakhulu kanye nevolumutagimodyuli ye-e eyenzelwe ukuqapha ngokunembile amazinga oketshezi, ivolumutage, kanye nokushisa. Ihlangana kahle nezinhlelo ze-Simarine PICO kanye ne-VIA, okwenza kube yisisombululo esifanele sokulungisa izikebhe ezikhona, campama-ervan, ama-trailer, nama-RV.
Izici ezibalulekile zifaka phakathi okokufaka kokumelana okungu-4, ama-vol angu-3tagokokufaka kwe-e, kanye nokudluliselwa kwesignali ye-alamu okuhleliwe okwakhelwe ngaphakathi, okunikeza amakhono okuqapha aphelele ezinhlelo zokusebenza ezahlukahlukene.
Isithombe 1: I-Simarine ST107 Tank Level Module. Lesi sithombe sibonisa ukwakheka okuhlangene kwe-module ye-ST107 enezindawo zayo zokufaka ezahlukahlukene kanye namachweba okuxhumeka kwedatha.
2. Yini EseBhokisini
- Imodyuli ye-Simarine ST107
- Ikhebula ledatha elingamamitha angu-5
- Izikulufu zokukhweza
- Incwadi Yomsebenzisi (le dokhumenti)
3. Ukusetha nokufakwa
Imodyuli ye-ST107 yenzelwe ukufakwa okulula, ikakhulukazi ezimweni zokulungisa izimoto nemikhumbi ekhona. Qinisekisa ukuthi ugesi unqanyuliwe ngaphambi kokuqala ukufakwa.
3.1. Ukufaka iModule
Khetha indawo eyomile, evikelekile yokufaka i-module ye-ST107. Sebenzisa izikulufo ezinikeziwe ukuze uqinise i-module endaweni eyisicaba. Qinisekisa ukuthi kunomoya owanele ozungeze i-module.
3.2. Izintambo zokuxhuma
I-ST107 inezingeniso ezizinikele zokumelana kanye nevolumutagizinzwa ze-e, kanye namachweba okuxhumeka kwedatha ye-SiCOM ukuze kuhlanganiswe nezinhlelo ze-Simarine PICO noma ze-VIA.
- Okokufaka Kokumelana (R1-R4): Xhuma izinzwa zezinga lethangi lohlobo lokumelana ne-analog noma izinzwa zokushisa (0 kuya ku-65,000 Ohms).
- VoltagOkufakiwe (U1-U3): Xhuma ivolumutagamabhethri e-e kuphela (ngaphandle kwe-lithium), i-analog voltagIzinzwa zezinga lethangi lohlobo lwe-e, noma izinzwa zomsebenzisi ezenziwe ngokwezifiso (0V kuya ku-75V).
- Amachweba e-SiCOM: Sebenzisa ikhebula ledatha elingamamitha angu-5 ukuxhuma i-ST107 kuyunithi yakho yokubonisa ye-Simarine PICO noma ye-VIA.
- I-Alamu Edluliselwe (CHA/NC/COM): Xhuma amadivayisi e-alamu angaphandle ku-relay ehlelekayo.
Umfanekiso 2: Ukuxhumeka Kokufaka kwe-ST107. Lo mdwebo ubonisa izinhlobo ezahlukene zokufaka kanye namaphuzu okuxhuma kumojuli ye-ST107, kufaka phakathi amachweba edatha ye-SiCOM, okokufaka kokumelana, ivolumutagokokufaka kwe-e, kanye nokudluliselwa kwesignali ye-alamu okulungisekayo.
Umfanekiso 3: Ububanzi Bezinzwa Ezisekelwayo. Lesi sithombe sichaza ububanzi bokusebenza kokufakwa kokumelana (0-65,000 Ohm), ivolumutagokokufaka kwe-e (0-75V), kanye nezinzwa zokushisa ze-NTC ezihambisanayo (1K, 5K, 10K).
4. Ukusebenzisa i-ST107 Module
Uma ixhunywe kusibonisi se-Simarine PICO noma se-VIA, imojula ye-ST107 inikeza idatha yesikhathi sangempela yamapharamitha ahlukahlukene. Ukucushwa nokuqapha kwenziwa ngqo ngeyunithi yesibonisi exhunyiwe.
4.1. Amapharamitha Okuqapha
I-ST107 ivumela ukuqapha:
- Amanzi, uphethiloli, noma amanye amazinga oketshezi (ngokumelana noma ivolumutagizinzwa ze-e)
- Voltagamabhethri angewona i-lithium
- Izinga lokushisa (ngezinzwa zokushisa ze-NTC)
- Izinzwa zomsebenzisi ezenziwe ngokwezifiso
Isithombe 4: Ukuboniswa Kwedatha Yesikhathi Sangempela. Lesi sithombe sibonisa iyunithi yokubonisa ye-Simarine PICO eveza idatha yesikhathi sangempela yamazinga ethangi (amanzi ahlanzekile, uphethiloli, imfucuza), voltage, kanye nokushisa, njengoba kulinganiswa yi-module ye-ST107.
4.2. I-Alarm Relay Engahlelwa
Ukudluliselwa kwesignali ye-alamu okuhleliwe okwakhelwe ngaphakathi kungalungiselelwa ukuqala i-alamu yangaphandle (kufika ku-1 amp) ngokusekelwe ezimweni ezichazwe ngaphambilini, njengamazinga ethangi aphansi noma aphezulu, noma amazinga okushisa. Bheka incwadi yakho ye-Simarine PICO/VIA ukuze uthole imininingwane yokucushwa kwe-alamu.
Umfanekiso 5: I-Alarm Signal Relay Engahlelwa. Lesi sithombe sigqamisa isici se-alamu, okubonisa ukuthi abasebenzisi bangaxwayiswa lapho amazinga amanzi noma amazinga okushisa ephansi kakhulu noma ephezulu kakhulu, nge-relay elungisekayo.
5. Isondlo
Imojuli ye-Simarine ST107 idinga ukulungiswa okuncane. Hlola njalo imojuli kanye nokuxhumeka kwayo ukuze ubone ukuthi iziphi izimpawu zokuguguleka, ukugqwala, noma umonakalo. Qinisekisa ukuthi konke ukuxhumana kuphephile.
- Gcina imodyuli ihlanzekile futhi yomile.
- Gwema ukubeka imodyuli emazingeni okushisa aphezulu noma elangeni eliqondile isikhathi eside.
- Ungazami ukuvula imojuli casing, njengoba lokhu kuzosusa iwaranti.
6. Ukuxazulula izinkinga
Uma uhlangabezana nezinkinga nge-module yakho ye-Simarine ST107, cabanga ngezinyathelo ezilandelayo zokuxazulula izinkinga:
| Inkinga | Imbangela Engenzeka | Isixazululo |
|---|---|---|
| Akukho datha eboniswa ku-PICO/VIA | Ukuxhumeka kwekhebula le-SiCOM okuxekethile; Imojula ayisebenzi; Izintambo zenzwa ezingalungile. | Hlola uxhumano lwekhebula le-SiCOM; Qinisekisa ukunikezwa kwamandla kumojuli; Hlola kabusha izintambo zenzwa ngokwencwadi yemiyalelo. |
| Ukufundwa okunganembile | Inkinga yokulinganisa inzwa; Uhlobo lwenzwa olungalungile lokufaka; Inzwa eyonakele. | Linganisa izinzwa ngesibonisi se-PICO/VIA; Qinisekisa ukuthi uhlobo lwenzwa olufanele luxhunywe kokufakwayo okufanele; Hlola inzwa ukuthi ayinawo umonakalo. |
| Ukudluliselwa kwe-alamu akuqalisi | Izimo ze-alamu azihlangatshezwanga; I-Relay ayilungiselelwanga kahle; Iphutha ledivayisi ye-alamu yangaphandle. | Qinisekisa imikhawulo ye-alamu kuzilungiselelo ze-PICO/VIA; Hlola ukucushwa kwe-relay; Hlola idivayisi ye-alamu yangaphandle ngokuzimela. |
Uma inkinga iqhubeka ngemva kokuzama lezi zinyathelo, sicela uxhumane nosekelo lobuchwepheshe be-Simarine.
7. Imininingwane
| Isici | Imininingwane |
|---|---|
| Inombolo Yemodeli | ST107 (Inombolo Yengxenye: 1940106) |
| Okokufaka Kokumelana | 4 (0 Ohm kuya ku-65,000 Ohm) |
| Voltage Okokufaka | 3 (0 V kuya ku-75 V) |
| I-Alarm Relay | Yakhelwe ngaphakathi, ingahlelwa (1) Amp ubuningi) |
| Ukuhambisana | I-Simarine PICO, i-Simarine VIA |
| Okubalulekile | Ipulasitiki, insimbi |
| Isisindo sento | 0.31 kg |
| Ubukhulu (L x W x H) | 9.45 x 7.28 x 2.17 amayintshi (Iphakheji) |
8. Ulwazi Lwewaranti
Imodyuli yeSimarine ST107 iza ne- Iwaranti yonyaka ongu-3 kusukela ngosuku lokuthenga. Lesi siqinisekiso simboza amaphutha ezintweni zokwakha kanye nokwakhiwa kwazo ngaphansi kokusetshenziswa okuvamile. Asimbozi umonakalo obangelwe ukufakwa okungafanele, ingozi, ukusetshenziswa kabi, ukusetshenziswa kabi, inhlekelele yemvelo, noma ukuguqulwa noma ukulungiswa okungagunyaziwe.
Ukuze uthole izimangalo zewaranti, sicela ugcine ubufakazi bakho bokuthenga bese uxhumana nosekelo lobuchwepheshe be-Simarine.
9. Ukusekelwa Kwezobuchwepheshe
Ukuze uthole usizo olwengeziwe, imibuzo yobuchwepheshe, noma ukwesekwa, sicela uxhumane noSimarine ngqo. Ungathola ulwazi lokuxhumana ku-Simarine esemthethweni. webindawo noma ngomdayisi wakho ogunyaziwe.
Umfanekiso 6: Usekelo Lobuchwepheshe. Lesi sithombe sibonisa izinketho zosekelo lobuchwepheshe, okuhlanganisa ukubhalela uSimarine noma ukubhukha ucingo lwevidiyo ukuze uthole usizo.
Ukuze uthole izinsiza zokusekela zakamuva kakhulu, vakashela i-Simarine esemthethweni webindawo: www.simarine.net
