1. Isingeniso
Thank you for choosing the Klarstein ACO7-1400-kbhn Electric Convector Heater. This manual provides essential information for the safe and efficient use of your new appliance. Please read these instructions thoroughly before installation and operation, and keep them for future reference.
This electric convector heater is designed to provide efficient and silent heating for various indoor spaces. It features a sleek design, adjustable thermostat, timer function, and can be used as a freestanding unit or wall-mounted.
2. Iziyalezo Zokuphepha
Ngaso sonke isikhathi qaphela lezi zinyathelo zokuphepha ezilandelayo ukuze unciphise ingozi yomlilo, ukushaqeka kukagesi, noma ukulimala:
- Funda yonke imiyalelo ngaphambi kokusebenzisa le heater.
- Le heater iyashisa uma isetshenziswa. Ukuze ugweme ukusha, ungavumeli isikhumba esingenalutho sithinte izindawo ezishisayo.
- Gcina izinto ezivuthayo, njengefenisha, imicamelo, izingubo zokulala, amaphepha, izingubo, namakhethini okungenani imitha elilodwa (amamitha amathathu) ukusuka ngaphambili kwesifudumezi futhi uzigcine kude nezinhlangothi nangemuva.
- Ukuqapha okukhulu kuyadingeka lapho noma iyiphi i-heater isetshenziswa noma eduze kwezingane noma abantu abangavumelekile futhi noma nini lapho i-heater ishiywa isebenza futhi ingagadiwe.
- Ungasebenzisi noma isiphi isifudumezi esinentambo noma ipulagi elonakele noma ngemuva kokungasebenzi kahle kwesifudumezi, siye sawiswa noma sonakala nganoma iyiphi indlela.
- Ungasebenzisi ngaphandle.
- Le heater ayihloselwe ukusetshenziswa ezindlini zokugezela, ezindaweni zokuwasha, nakwezinye izindawo ezifanayo zasendlini. Ungalokothi uthole i-heater lapho ingawela khona kubhavu noma kwesinye isitsha samanzi.
- Ungagijimi intambo ngaphansi kokhaphethi. Ungavali intambo ngamaragi okujikijela, abagijimi, noma izimbozo ezifanayo. Hlela intambo kude nendawo yethrafikhi nalapho ingeke ikhubeke khona.
- Ukuze unqamule i-heater, vala izilawuli, bese ukhipha ipulaki kokuphumayo.
- Ungafaki noma uvumele izinto zangaphandle ukuthi zingene kunoma iyiphi indawo yokukhipha umoya noma indawo yokukhipha umoya ngoba lokhu kungase kubangele ukushaqeka kukagesi noma umlilo, noma kulimaze ihitha.
- Ukuze uvimbele ukuqubuka komlilo, ungavimbi ukungena komoya noma i-exhasi nganoma iyiphi indlela. Ungasebenzisi ezindaweni ezithambile, njengombhede, lapho izimbobo zingavaleka khona.
- Heaters have hot and arcing or sparking parts inside. Do not use it in areas where gasoline, paint, or flammable liquids are used or stored.
- Sebenzisa le heater kuphela njengoba kuchazwe kuleli bhukwana. Noma yikuphi okunye ukusetshenziswa okunganconyiwe umenzi kungadala umlilo, ukushaqeka kukagesi, noma ukulimala kwabantu.
- Lolu hlelo lokusebenza lufakwe ukuvikela ukushisa ngokweqile. If the heater overheats, it will automatically shut off. Unplug the heater and allow it to cool down before restarting.
3. Izingxenye Zomkhiqizo
The Klarstein ACO7-1400-kbhn Electric Convector Heater includes the following main components:
- Convector Heater Unit with integrated display
- Isilawuli kude
- Set of Wheels for freestanding use
- Wall Mounting Kit (brackets, screws, anchors)
- Power Cable (1.5m length)
Umfanekiso 3.1: Ngaphambili view of the convector heater with its digital display.
Figure 3.2: The convector heater shown with its included remote control.
4. Ukusetha nokufakwa
The Klarstein ACO7-1400-kbhn heater offers two installation options: freestanding with wheels or wall-mounted.
4.1 Ukufakwa Okuzimele
- Khipha ngokucophelela i-heater nazo zonke izesekeli.
- Attach the provided wheels to the base of the heater using the included screws. Ensure they are securely fastened.
- Place the heater on a stable, level surface, ensuring adequate clearance from walls and combustible materials (at least 1 meter).
- Xhuma ikhebula lamandla endaweni kagesi efanelekile.
Figure 4.1: Heater with wheels attached for portable, freestanding use.
4.2 Ukufakwa Okufakwa Odongeni
- Select a suitable wall location, ensuring it is away from curtains, furniture, and other flammable objects. Maintain a minimum distance of 1 meter from any combustible material.
- Using the wall mounting kit, mark the positions for drilling holes on the wall.
- Geza izimbobo bese ufaka amahange odongeni.
- Namathisela amabakaki okukhweza odongeni usebenzisa izikulufu ezinikeziwe.
- Carefully hang the heater onto the wall brackets, ensuring it is securely seated.
- Xhuma ikhebula lamandla endaweni kagesi efanelekile.
Umfanekiso 4.2: Eksample of the heater wall-mounted in a bathroom, suitable for humid environments due to IP24 protection.
The heater is suitable for various rooms, including living rooms, bedrooms, and offices. Thanks to its IP24 protection class, it can also be safely installed in humid rooms like bathrooms or kitchens.
5. Iziqondiso Zokusebenza
The heater can be operated via the touch control panel on the unit or the included remote control.
5.1 Vula/Vala amandla
- Cindezela inkinobho Inkinobho yamandla (
) kuphaneli yokulawula noma kusilawuli kude ukuze uvule noma uvale i-heater.
5.2 Ukusetha Izinga lokushisa
- Sebenzisa i- Up futhi Phansi buttons on the control panel or remote to adjust the desired room temperature. The digital display will show the set temperature.
- The integrated thermostat will maintain the set temperature, turning the heating element on and off as needed.
5.3 Umsebenzi Wesibali sikhathi
- Cindezela inkinobho Inkinobho yesibali sikhathi to set an automatic shut-off time. The display will show the remaining time.
- Adjust the timer duration using the Up and Down buttons.
5.4 Heat Settings (Power Levels)
The heater typically offers two power levels (e.g., 1000W and 2000W) for flexible heating. Refer to the display or remote control for specific buttons to switch between these modes.
5.5 Button Lock
The heater includes a button lock feature to prevent accidental changes to settings, especially useful in households with children. Consult the manual for specific instructions on activating and deactivating the button lock.
Figure 5.1: Close-up of the control panel and digital display, showing temperature and function icons.
6. Isondlo
Ukunakekelwa okuvamile kuqinisekisa ukuphila isikhathi eside nokusebenza kahle kwe-heater yakho.
6.1 Ukuhlanza
- Njalo khipha i-heater futhi uyivumele iphole ngokuphelele ngaphambi kokuhlanza.
- Sula ingaphandle ngethafa elithambile, damp indwangu. Ungasebenzisi izinto zokuhlanza abrasive noma izincibilikisi.
- Qinisekisa ukuthi amanzi awangeni ngaphakathi kwe-heater.
- Clean the air intake and exhaust vents regularly with a vacuum cleaner to remove dust and debris.
6.2 Isitoreji
- If storing the heater for an extended period, clean it thoroughly and store it in its original packaging or a protective cover.
- Gcina endaweni epholile, eyomile, kude nelanga eliqondile kanye nomswakama.
7. Ukuxazulula izinkinga
If you encounter issues with your Klarstein convector heater, refer to the following troubleshooting guide:
| Inkinga | Imbangela Engenzeka | Isixazululo |
|---|---|---|
| I-heater ayivuli | Akukho ukunikezwa kwamandla Ukuvikela ukushisa ngokweqile kuvuliwe Inkinobho yamandla ayicindezelwanga | Check if the plug is securely in the outlet and the circuit breaker is on. Unplug, let cool for 30 minutes, then plug back in. Press the power button on the unit or remote. |
| Heater produces no heat | Izinga lokushisa liphansi kakhulu Room temperature reached Ukungasebenzi kahle kwesici sokushisa | Khulisa izinga lokushisa olifunayo. This is normal operation; the heater will resume heating when the room temperature drops. Xhumana nokwesekwa kwamakhasimende uma inkinga iqhubeka. |
| Isilawuli kude asisebenzi | Amabhethri afile noma afakwe ngokungalungile Obstruction between remote and heater Ukungasebenzi kahle kwesilawuli kude | Shintsha amabhethri futhi uqinisekise i-polarity efanele. Susa noma yiziphi izinto ezivimba indlela yesignali. Try operating the unit directly via the control panel. If the remote still fails, contact customer support. |
| Umsindo noma iphunga elingavamile | Ukunqwabelana kothuli Inkinga yengxenye yangaphakathi | Unplug the heater and clean the vents. A slight smell may occur during first use. If persistent or strong, unplug immediately and contact customer support. |
8. Imininingwane
Key technical specifications for the Klarstein ACO7-1400-kbhn Electric Convector Heater:
| Isici | Ukucaciswa |
|---|---|
| Ibhrendi | KLARSTEIN |
| Inombolo Yemodeli | ACO7-1400-kbhn |
| Umbala | Mnyama |
| Amandla | Up to 2000 Watts (with 2 speed settings) |
| Voltage | 220 volts |
| Ubukhulu (L x W x H) | 24.5 x 51.5 x 45 cm |
| Isisindo Somkhiqizo | 6.3 kg |
| Izici ezikhethekile | Easy to use, Overheating Protection, Timer, Electric Thermostat, Button Lock |
| Indlela Yokushisisa | Ingqungquthela |
| Uhlobo Lokukhweza | Freestanding / Wall-mounted |
| Ikilasi Lokuvikela | IP24 (suitable for humid rooms) |
Umfanekiso 8.1: I-Dimensional ngaphezuluview ye-heater ye-convector.
9. Iwaranti kanye Nokusekela
For warranty information, please refer to the warranty card included with your product or visit the official Klarstein website. If you require technical support or have questions not covered in this manual, please contact Klarstein customer service through their official channels.
You can often find support contact details on the Klarstein brand store page: Klarstein Amazon Store
